CNP Pump 25L 1500BPH PET Bottle Filling Machine 5 Gallon

Name: CNP Pump 25L 1500BPH PET Bottle Filling Machine 5 Gallon
Brand: Aquatrin
Price: 2000 USD

Quality CNP Pump 25L 1500BPH PET Bottle Filling Machine 5 Gallon for sale

Brand Name : Aquatrin

Model Number : QGF

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Price : USD2000-60000 1Set

Payment Terms : T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Packaging Type : Barrel, Bottles

Usage : Water Filling 5 Gallon

Filling method : Gravity filling

Pump : CNP pump

Control manner : PLC and touch screen

Electric parts : Siemens/Mitsubishi/Schneider/ABB etc.

Contact Now

Product Description
Brief Introduction


The series of machine integrate rinsing,contain rinser-filler-capper monoblock,automatic loading machine,bottle outside washer,bottle inside washer,decapper,heating shrink tunnel,conveyor system,complete line control system.
The whole filling speed ranges from 100BPH to 1500BPH.
 Filling the pure water or the mineral water in 3 or 5 gallons.


 	 			Product Name 			Automatic Mineral Water 5 Gallon Bottle Filling Machine / Production Line
 			Capacity 			100~1200 barrels per hour
 			Control 			PLC control
 			Filling heads 			1-12pcs
 			Suitable barrel 			3 -5 gallon/10-25L
 			Processing type 			Washing+filling+capping
 			Features 			1. This filling line specially produces 3&5 gallons barreled drinking water.
 			2. This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
 			3. In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
 			4. This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
 			5. This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.
 			6. It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.






Complete Production Line

CNP Pump 25L 1500BPH PET Bottle Filling Machine 5 Gallon

De-capping machine

Water treatment system refers to the measures taken to make the water quality meet certain use standards. The physical characteristics of water, such as temperature, color, transparency, odor and taste, are filtered or treated so that water can be used directly for drinking or other purposes.

External brusher

Water treatment system refers to the measures taken to make the water quality meet certain use standards. The physical characteristics of water, such as temperature, color, transparency, odor and taste, are filtered or treated so that water can be used directly for drinking or other purposes.

Inside washing-filling-capping machine

Working processing: - Hot alkaline water rinsing
- Dripping
- Detergen water filling
- Dripping
- Recycling water rinsing
- Dripping
- Pure water rinsing
- Filling
- Capping
- Customize

Water Treatment System

Water treatment system refers to the measures taken to make the water quality meet certain use standards. The physical characteristics of water, such as temperature, color, transparency, odor and taste, are filtered or treated so that water can be used directly for drinking or other purposes.

Automatic Sleeve Shrink Labeling Machine

Shrink Labeling Machine For Sleeve adpots PLC programmable controller,imported servo motor,servo driver, frequency converter and transducer.
Shrink Labeling Machine For Sleeve adopts the positioning module to ensure the casting label precise,rapid and stable.
Our Shrink Labeling Machine For Sleeve not only has a highly precise position for casting label, but also withstand the perfect shape of the bottle after shrinkage.

Automatic Bagging machine

- Automatic bagging machine adopts aluminum alloy knife with teflon coating and anti-adhesion. - High packing efficiency.

PET Bottle Blow Molding System

1). Stable performance with advanced PLC.
 2). Preform self-rotation and infrared pre-heater revolution assure the even distribution of heat, which improve the bottle shaping rate, increase the production.
 3). High adjusting performance to enable preheat the preforms perfectly by adjust the voltage control area in the PLC, which could
 adjust the temperature of the infrared lights in the pre-heater, and keep the proper temperature and humidity invariable.

Machnical Drawing

CNP Pump 25L 1500BPH PET Bottle Filling Machine 5 Gallon

Electric Configuration

Item	Product name	Brand	Origin
1	Automatic switch	Meilarila	France
2	AC contactor	Schneider	France
3	PLC	Mitsubishi	Japan
4	Electric switch	Schneider	France
5	Pump	CNP	China
6	Cylinder of principal axis	Airtac	Taiwan
7	Cylinder of up and down	Airtac	Taiwan
8	Cylinder of cap press	Airtac	Taiwan
9	Cylinder of jar push	Airtac	Taiwan
10	Cylinder of filling valve	Airtac	Taiwan
11	Air pressure processing system	Airtac	Taiwan
12	Air pipe fittings	Airtac	Taiwan
13	Nozzle	Domestic	Shanghai
14	Chain	SUS304	China
15	The valve of water inlet	SUS304	China
16	Filling valve	SUS304	China
